The Flameshield EW 120 range at a glance
Flameshield EW120
Integrity: 120 minutes
Radiation W @ 15kw/m2: 120 minutes
Smoke to BS 1634-3: No
Max. Width: 5,000mm*
Max. Height: 6,000mm*
Flameshield EW120 S
Integrity: 120 minutes
Radiation W @ 15kw/m2: 120 minutes
Smoke to BS 1634-3: Yes
Max. Width: 5,000mm*
Max. Height: 6,000mm*
Flameshield EW120 MaxS
Integrity: 120 minutes
Radiation W @ 15kw/m2: 120 minutes
Smoke to BS 1634-3: Yes
Max. Width: 10,000mm*
Max. Height: 4,000mm*
Proven Standards
Tested under BS 8524-1, BS 8524-2 and BS EN 1634-3.
Radiation Excellence
Achieving 10.71 kW/m2 at 120 minutes. Well under the 15 kW/m2 threshold.
Wide Applications
Suitable where occupant safety, visibility, and design aesthetics converge.
Why use the Flameshield EW120 Range
The Flameshield EW120 range are a collection of high-performance active fire and smoke curtains, rigorously tested to the principles of BS 8524-1, BS 8524-2, and BS EN 1634 to provide superior fire containment.
Designed to deploy seamlessly from a concealed head box, these state-of-the-art fire protection systems automatically descend during a fire.
With up to 120 minutes of fire protection, an industry-leading 120 minutes of radiation protection, and fail-safe operation, the Flameshield EW120 range exceeds expectations globally.
